Product Details:
|
| Model Number:: | 3-9x50E Tactical Hunting Scope | Magnification: | 3X-9X |
|---|---|---|---|
| Objective Diameter: | 50MM | Eye Relief: | 66.8-99.06mm |
| Net Weight: | 505g | Length: | 312mm |
| Field Of View(@100yds): | 13.41-40.38@100yds | Shock/fogproof: | Yes |
| High Light: | 3-9x50E Tactical Hunting Scope,Red And Green military grade scopes 505g,3-9x50E military grade scopes |
||
3-9x50E Red And Green Illumination Tactical Hunting Scope With High Turret Cover
3-9x50E Red And Green Illumination Tactical Hunting Scope With High TurretCover can be used in shooting games ,Outdoor hunting
Focusing
Look through scope within 3 or 4 inch distance from your eye to eyepiece lens. If you can't see the reticle clearly, loosen knurled lock ring and rotate eyebell until the reticle appears clearest. Then scre the lock ring to lock the eye bell firmly
Adjusting magnigication
Manification of the scope with magnification adjusing system can be varied by rotating power ring.
Adjudting distance
Superior riflescope has distance adjusting device. When shooting at a target, rotate distance rign to corresponding position.
Boresighting
| impact point | left up | left down | right up | right down |
| (turn direction) up hand wheel | clock wise | counter clock wise | clock wise | clock wise |
| (turn direction) lefr handwheel | counter clock wise | clock wise | clock wise | clock wise |
Technical paramter
| Model | Actual Magnification | Obj-Lens Aperture(mm) | Field of view(ft.) | Weight(ozs) | Length(in.) | Eye Relief(in.) | Exit Pupil(mm) | Click Value at 100yds(in.) |
|
MA-1 MA-2 MA-3 MB-1 MB-3 MC-1 MD-2 MJ-1 MK-2 ML-2 MN-1 MO-1 MP-1 MQ-1 |
4X 4X 4X 3X-9X 3X-9X 3X-9X 4X 2X 4X 6X 4X-12X 3X-9X 2.5X 4X |
32 32 32 32 32 40 15 20 40 40 40 56 20 20 |
29 28 29 42~13 39~13 25~14 17 10 29 20 27~10 35~6.3 44 30 |
9 9
10 11 12 4.5 6
14.5 18
|
11.8 11.8
12 11.8 12.2 11 8.3
13 13.8
|
2.95 3 3.3 3.5~2.6 3.5~2.6 3.3~2.7 3 14.6 3.7 3.1 3.4~3 3.7~2.6 4.1 3.7 |
8 8 8 10.7~3.6 10.7~3.6 13.3~4.4 2 12.4 10 6.66 10~3.3 18.7~6.2 8 5 |
0.5 0.25 0.25 0.25 0.25 0.25
0.25 0.25 0.25 0.25 0.25 0.25 |
Package Contents
·
· 1X 3-9X50ETactical Hunting Scope
· 1X Product Instruction
· 1X Allen Wrench
· 1X Lens Cleaning cloth
· 1X CR2032
· 1X Protective Cap
